NIST SP 800-171A, Assessing Security Requirements for Controlled Unclassified Information (June 2018)
  • Classification
    Category
    Cybersecurity
    Domain
    Cybersecurity
    Framework Family
    NIST Special Publications
  • Regulatory Context
    Type
    Assessment / Maturity Model
    Legal Instrument
    Guideline
    Sector
    Defense Sector
    Industry
    Government & Public Sector
  • Region / Publisher
    Region
    Global
    Region Detail
    United States
    Publisher
    National Institute of Standards and Technology (NIST)
  • Versioning
    Version
    June 2018 edition; withdrawn May 14, 2024
    Effective Date
    June 13, 2018
    Issue Date
    June 13, 2018
  • Adoption
    Adoption Model
    Regulatory Compliance
    Implementation Complexity
    High
  • Official Reference
License Information

License included / downloadable: Yes

NIST SP 800-171A is free of charge from NIST; the PDF is the authoritative text, and the CSRC record also offers the procedures as CSV and XLSX files.

Framework text is licensed by its publisher and is included only where stated above.

Official Resources
NIST SP 800-171A Document
Provides assessment procedures for security requirements of Controlled Unclassified Information.
NIST SP 800-171 Revision 2
Outlines the requirements for protecting Controlled Unclassified Information in non-federal systems.
Key takeaways
  • NIST SP 800-171A (June 2018) is the withdrawn first edition of the assessment procedures for the CUI security requirements in SP 800-171.
  • NIST withdrew it on May 14, 2024, but 32 CFR 170 and DFARS 252.204-7020 still incorporate the June 2018 edition for CMMC and DoD assessments.
  • It holds one procedure for every requirement in the fourteen families, each with an assessment objective, methods, and objects.
  • Each objective is split into lettered determination statements, so a result can be traced back to the requirement text.
  • SmartSuite Compliance Management holds the 110 requirements and their determination statements with evidence attached.

Overview

NIST SP 800-171A (June 2018) is the withdrawn first edition of NIST's assessment procedures for the Controlled Unclassified Information (CUI) security requirements in SP 800-171: NIST withdrew it on May 14, 2024 and superseded it with SP 800-171A Rev. 3. It is still the edition the Department of Defense incorporates by reference. 32 CFR 170.14(d) prescribes NIST SP 800-171A Jun2018 for assessing the CMMC security requirements, 32 CFR 170.16 and 170.17 require Level 2 self-assessments and C3PAO certification assessments to follow it, 32 CFR 170.18 applies it to Level 3 assessments by DCMA DIBCAC, and DFARS 252.204-7020 defines a High Assessment as one conducted by Government personnel using NIST SP 800-171A.

The National Institute of Standards and Technology (NIST) published the edition on June 13, 2018; its authors are Ron Ross, Kelley Dempsey and Victoria Pillitteri. The abstract describes assessment procedures and a methodology that federal and nonfederal organizations can use to assess the CUI security requirements in SP 800-171. Chapter Three holds one procedure for every requirement in the fourteen families, from 3.1 Access Control to 3.14 System and Information Integrity, and each procedure consists of an assessment objective made of determination statements plus potential assessment methods and objects (Section 2.1).

Organizations use the procedures to generate evidence that the requirements have been satisfied (Section 1.1). Assessments can be self-assessments, independent third-party assessments or government-sponsored assessments, applied with customer-defined depth and coverage attributes (abstract and Appendix D). For DoD contractors the results become the summary level scores posted in the Supplier Performance Risk System (SPRS) under DFARS 252.204-7020, which also records the version of SP 800-171 against which the assessment was conducted, and under 32 CFR 170.16 a plan of action and milestones (POA&M) closeout self-assessment follows the same procedures.

Why does it matter?

NIST SP 800-171A (2018) matters because it turns 110 security requirements into questions an assessor can answer. Each assessment objective is split into lettered determination statements that are linked to the text of the requirement, so a result can be traced back to the words that caused it (Section 2.1). Requirement 3.1.1, for example, yields six statements, 3.1.1[a] authorized users are identified through 3.1.1[f] system access is limited to authorized devices. Because the CMMC rule in 32 CFR 170 and the DFARS assessment clauses incorporate this June 2018 edition rather than Rev. 3, contractors in the defense supply chain still need its exact statements.

Key benefits include:

  • Traceable determinations

Every assessment objective is a set of determination statements tied to the requirement text, so findings trace to the requirement and the evidence that supports them (Section 2.1).

  • Three methods, four kinds of object

Examine, interview and test are applied to specifications, mechanisms, activities and individuals, which lets an organization pick the mix that gives sufficient confidence at the lowest cost (Section 2.1).

  • Adjustable rigor

Depth and coverage attributes run from basic to focused to comprehensive, each value building on the one before, so the same procedure serves a light self-check or a full certification assessment (Appendix D).

  • An assurance case, not a checklist

Evidence from self-assessments, third-party product testing and life cycle artifacts is organized into an argument that the requirements are met (Section 2.2).

  • The edition the DoD assesses against

32 CFR 170.14(d), 170.16, 170.17 and 170.18 and DFARS 252.204-7020 name this edition, so a CMMC or DIBCAC result is scored on its statements.

How does it work?

An assessment procedure has three parts (Section 2.1). The security requirement is quoted first. The assessment objective follows, introduced by the words Determine if and listing the determination statements, such as 3.1.3[a] information flow control policies are defined through 3.1.3[e] approved authorizations for controlling the flow of CUI are enforced. The potential assessment methods and objects close the procedure: an Examine list of documents such as the access control policy, system security plan and audit records, an Interview list of roles such as system or network administrators, and a Test list of the mechanisms that implement the requirement. Figure 1 uses requirement 3.1.3 as the worked example.

Organizations are not expected to employ every method and object listed. Section 2.1 says they have the flexibility to decide the level of effort and the assurance an assessment needs, choosing the methods and objects most useful for reaching the objectives in the most cost-effective manner with sufficient confidence. Appendix D defines the three methods, the objects each can be applied to, and the depth and coverage attributes in Tables D-1 through D-3, with bold text marking what each higher attribute value adds. Footnote 6 points to SP 800-53A for the full treatment of those attributes.

Section 2.2 describes the assurance case: a body of evidence organized into an argument that the system complies with the SP 800-171 requirements. Evidence can come from self-assessments, independent third-party assessments or other assessments, and product assessments by independent testing organizations can stand in for parts of it. Assessments can be conducted by system developers, system integrators, auditors, system owners or the organization's own security staff. Section 1.1 lists five uses of the evidence: identifying shortfalls in security and risk management programs, finding weaknesses and deficiencies, prioritizing mitigation, confirming that deficiencies have been addressed, and supporting continuous monitoring.

Key Elements

  • Chapter One, Introduction

Sections 1.1 purpose and applicability, 1.2 target audience and 1.3 organization; it explains that Executive Order 13556 created the CUI Program and 32 CFR part 2002 implements it.

  • Chapter Two, The Fundamentals

Section 2.1 assessment procedures (objectives, determination statements, methods and objects) and Section 2.2 assurance cases.

  • Chapter Three, The Procedures

Procedures for the fourteen families: 3.1 Access Control, 3.2 Awareness and Training, 3.3 Audit and Accountability, 3.4 Configuration Management, 3.5 Identification and Authentication, 3.6 Incident Response, 3.7 Maintenance, 3.8 Media Protection, 3.9 Personnel Security, 3.10 Physical Protection, 3.11 Risk Assessment, 3.12 Security Assessment, 3.13 System and Communications Protection and 3.14 System and Information Integrity.

  • Appendix A, References

The sources cited, including SP 800-171 Revision 1 of December 2016, the edition the procedures were written for.

  • Appendices B and C

Glossary of the terms used, including assessment object, assessment method and determination statement, and the acronym list.

  • Appendix D, Assessment Methods

Definitions of examine, interview and test, the objects each applies to, and the basic, focused and comprehensive values of the depth and coverage attributes in Tables D-1 through D-3.

  • Data formats and the SSP template

The CSRC record (planning note of April 13, 2022) offers the procedures as CSV and XLSX files, with the PDF as the normative source, and a CUI system security plan template keyed to requirement 3.12.4.

What does it cover?

NIST SP 800-171A (2018) applies to assessments of the CUI security requirements in SP 800-171 wherever CUI resides in nonfederal systems and organizations. CUI is federal information that a law, regulation or governmentwide policy requires to be safeguarded, as established by Executive Order 13556 and 32 CFR part 2002 (Chapter One). The procedures were written for SP 800-171 Revision 1 and were used for Revision 2, the version 32 CFR 170.14 incorporates for CMMC Level 2 and DFARS 252.204-7012 requires of covered contractor information systems. They do not cover the 97 requirements of SP 800-171 Rev. 3, which have their own procedures in SP 800-171A Rev. 3.

What are its objectives?

Section 1.1 states what the assessment process is for:

To generate evidence that supports the assertion that the SP 800-171 security requirements have been satisfied.

To identify potential problems or shortfalls in the organization's security and risk management programs.

To identify security weaknesses and deficiencies in systems and in the environments in which they operate.

To prioritize risk mitigation decisions and activities, and to confirm that identified weaknesses have been addressed.

To support continuous monitoring activities and provide information security situational awareness.

Framework in Context

NIST SP 800-171A (2018) is the companion to SP 800-171 Rev. 2, whose 110 requirements it assesses, and it draws its methods and attributes from SP 800-53A (Section 2.1, footnote 6). NIST replaced both on May 14, 2024, and SP 800-171A Rev. 3 now covers the 97 requirements of SP 800-171 Rev. 3 with organization-defined parameters in its determination statements. The DoD has not followed: 32 CFR 170.14(d) incorporates NIST SP 800-171A Jun2018 for CMMC, 32 CFR 170.16 to 170.18 apply it at Levels 2 and 3 alongside SP 800-172A Mar2022, and DFARS 252.204-7020 posts Basic, Medium and High Assessment scores to SPRS with the SP 800-171 version named. A contractor keeps this edition until its clauses change.

Common Framework Mappings

NIST SP 800-171A (2018) is commonly mapped to the catalogs and assessment programs that reuse its determination statements, so one body of assessment evidence can serve several reviews.

Mapped frameworks include:

CIS Controls v8.1

CMMC 2.0

COBIT 2019

FedRAMP Rev. 5

HIPAA

ISO 27001:2022

NIST CSF 2.0

NIST 800-53 Rev.5

PCI DSS 4.0.1

SOC 2

SMARTSUITE

How SmartSuite Supports NIST SP 800-171A (2018)

SmartSuite provides the system for managing controls, evidence, mappings, assessments, and reporting.

Use Compliance Management to hold the 110 requirements and their lettered determination statements as records with evidence attached, Internal Audit Management to plan and run self-assessments and DIBCAC-style reviews against them, and Cyber & IT Risk to link each unmet statement to the risk it leaves open.

Determination Statement Register

Record each requirement with its determination statements, for example 3.1.1[a] through 3.1.1[f], as linked records in Compliance Management so a finding is made per statement (Section 2.1).

Methods and Objects per Procedure

Capture which examine, interview and test methods and which specifications, mechanisms, activities and individuals were selected for each procedure, with the depth and coverage value chosen (Appendix D).

Evidence for the Assurance Case

Attach policies, system security plan extracts, configuration records and test results to the statements they support so the Section 2.2 assurance case is assembled from the records themselves.

Assessment Plans and Reviews

Use Internal Audit Management to schedule self-assessments, C3PAO certification assessments and DIBCAC High Assessments, assign assessors and track fieldwork to completion.

Open Findings and POA&M Items

Track each determination not yet met in Cyber & IT Risk with an owner and due date, and record the POA&M closeout self-assessment that 32 CFR 170.16 requires within 180 days.

SPRS Score Record

Keep the summary level score, the assessment date and the SP 800-171 version assessed, the three items DFARS 252.204-7020 posts to SPRS, with each submission as a record for reporting.

Related frameworks

CIS Controls v8.1

CIS Controls v8.1 is a prioritized set of 18 Controls and 153 Safeguards, in three Implementation Groups, with a new Govern function.

CMMC 2.0

CMMC is the DoD program, 32 CFR Part 170, that requires contractors handling FCI or CUI to hold a Level 1, 2 or 3 status. Phase 2 was suspended on July 13, 2026.

ISO 27001:2022

ISO/IEC 27001:2022 specifies requirements for an information security management system: Clauses 4 to 10, risk treatment, the Statement of Applicability and 93 Annex A controls.

ISO 27002:2022

ISO/IEC 27002:2022 is the reference set of 93 information security controls in four themes, with attributes and implementation guidance, that supports an ISO/IEC 27001 ISMS.

NIST CSF 2.0

NIST CSF 2.0 (CSWP 29, February 26, 2024) is the voluntary cybersecurity framework with six Functions including Govern, 22 Categories, 106 Subcategories, Profiles and Tiers.

NIST 800-53 Rev.5

NIST SP 800-53 Rev. 5 is the NIST catalog of security and privacy controls in 20 families, mandatory for federal systems under OMB A-130 and FISMA; Release 5.2.0 issued August 27, 2025.

SOC 2

SOC 2 is the AICPA examination, under AT-C 105 and 205, of a service organization's controls against the 2017 Trust Services Criteria, issued as a type 1 or type 2 attestation report.

PCI DSS 4.0.1

PCI DSS v4.0.1 (June 2024) is the current Payment Card Industry Data Security Standard: twelve requirements, two validation approaches and the dates that retired v4.0.

FAQ

Frequently Asked Questions For NIST SP 800-171A (Assessing Security Requirements for Controlled Unclassified Information)

NIST withdrew the June 2018 edition on May 14, 2024, when SP 800-171A Rev. 3 superseded it, but the DoD rules still name it. 32 CFR 170.14(d) says assessment of the CMMC security requirements is prescribed by NIST SP 800-171A Jun2018, 32 CFR 170.16 and 170.17 require Level 2 self-assessments and C3PAO certification assessments to follow it, 32 CFR 170.18 applies it with SP 800-172A Mar2022 at Level 3, and DFARS 252.204-7020 defines a High Assessment as one conducted by Government personnel using NIST SP 800-171A.

Each procedure quotes the security requirement, states an assessment objective as a list of determination statements, and lists potential assessment methods and objects (Section 2.1). For requirement 3.1.1 the objective runs from 3.1.1[a] authorized users are identified to 3.1.1[f] system access is limited to authorized devices, followed by Examine, Interview and Test lists that name the documents, roles and mechanisms an assessor can select from.

Examine is reviewing, inspecting, observing, studying or analyzing assessment objects; interview is holding discussions with individuals or groups; test is exercising activities or mechanisms under specified conditions to compare actual with expected behavior (Section 2.1). Depth sets the rigor and level of detail and coverage sets the scope, each with the values basic, focused and comprehensive, and Appendix D Tables D-1 through D-3 describe what each value adds.

The abstract allows self-assessments, independent third-party assessments and government-sponsored assessments, and Section 2.2 says assessments can be conducted by system developers, system integrators, auditors, system owners or the organization's security staff. Under DFARS 252.204-7020 a Basic Assessment is a contractor self-assessment, while Medium and High Assessments are conducted by the Government, the High Assessment using SP 800-171A.

Appendix A cites SP 800-171 Revision 1 of December 2016, the edition in force when the procedures were written, and the same fourteen-family structure carried into Revision 2 (February 2020), which 32 CFR 170.14 incorporates for CMMC Level 2. The 97 requirements of SP 800-171 Rev. 3 use a different numbering with organization-defined parameters and are assessed with SP 800-171A Rev. 3, not this edition.
